ANYCERT-CE/TUV-NYM NYM-J/NYM-O

Structure

Complies with VDE0295 / IEC228 Class 1 or Class 2 conductor.
Special PVC mixed insulation.
With inner sheath.
Special PVC mixture outer sheath.

Characteristic

Flame retardant,No harmful substances, RoHS compliant
Comply with CE / TUV and other standards
NYM-O: No green / yellow ground wire.
(the remaining cores can be colored or numbered coded)
NYM-J: a green / yellow color ground wire.
(the remaining cores can be colored or numbered coded)

Performance

Rated voltage: 300 / 500V
Test voltage: 2000V
Minimum bending radius:
4 × cable outer diameter
Temperature range:
Mobile installation: -5 ℃ to + 50 ℃
Fixed installation: -40 ℃ to + 70 ℃
Flame retardant: IEC 60332.1
